Discover Xinjiang Yihua's two vacuum hot water boilers for efficient heating solutions. Manufactured in Xinjiang Uygur Autonomous Region.
Description
Supply ZKT-1.4N fully premixed ultra-low nitrogen fully condensing vacuum phase change hot water boilers to Xinjiang Yihua Plastic Industry Co., Ltd. in Xinjiang Uygur Autonomous Region to meet the winter heating needs of its factory area.
The ZK(WY)T series fully premixed ultra-low nitrogen fully condensing vacuum (micro-pressure) phase change hot water boiler, featuring environmental protection, energy conservation, safe and stable operation, fully guarantees winter heating for production workshops and employee dormitories, and supports Hubei Yihua Group's development strategy of taking root in Xinjiang.
Environmental protection and energy conservation
1. Integrated water-cooled surface combustion, precise air-fuel ratio control, always maintaining the best mixing ratio, low-temperature blue flame combustion, more complete combustion, ensuring ultra-low emissions of harmful substances; The nitrogen oxide emissions during operation are far below 20mg/m³.
2. The brand-new structural design and advanced two-stage (air preheating + flue gas condensation) condensation heat exchange technology not only maximize heat output but also fully absorb the residual heat in the flue gas, achieving extremely high thermal efficiency. During operation, the flue gas temperature is only 3 to 5 degrees Celsius higher than the return water temperature, and the thermal efficiency reaches 104 to 106%, significantly reducing the heating cost in winter.
High-quality accessories
1. It adopts top international brand fans, which are of reliable quality, stable operation and extremely low noise.
2. The gas valve group adopts international top brands such as Siemens, Dongs or Honeywell, which can provide precise proportional control to ensure the reliability and safety of combustion.
3. Advanced compact matrix water pipe structure design, dual-stage condensation heat exchange technology, built-in fully premixed water-cooled surface combustion, stainless steel straight tube heat exchanger, multi-functional in one machine, can easily achieve multi-circuit pressure direct supply with different temperature differences and flow rates.
4. The boiler operates under vacuum, free from scaling and corrosion. The heat transfer water and system water are isolated, ensuring an extremely long service life of the boiler.
Convenient for operation and maintenance
1. Fully intelligent one-click operation, real-time dynamic operation interface, automatic recording of operation data, more user-friendly operation, complete safety protection, efficient, stable and safe operation, and can easily achieve Internet of Things connection.
2. Complete intelligent protection, combined with multiple mechanical protection devices, ensures constant temperature output of the boiler without frequent starts, guaranteeing the safe, stable and efficient operation of the boiler.
3. The boiler is equipped with an internal heat exchanger, so the heat transfer water does not need to be replaced. There is no need to be equipped with an external plate heat exchanger or a boiler circulation pump. The boiler room has fewer devices and requires less maintenance work.
Operate safely and stably
It is equipped with gas valve groups of international first-line brands and various protection functions of the burner to ensure the safe operation of the equipment.
2. The water level of the heat medium can be directly observed through a stainless steel sight glass and is equipped with a water shortage protection function.
3. Local vacuum pressure display/controller display, vacuum pressure controller overpressure protection, gravity safety door positive pressure protection.
4. Over-temperature protection for supply water temperature, return water temperature, heat medium water temperature, flue gas temperature, etc.
5. Dual load control of outlet water temperature and heat medium water temperature, and precise matching of fan speed to heat demand.
